5.8GHz 18dBi WiFi Directional Panel Antenna N female
5.8GHz 18dBi WiFi Directional Panel Antenna N female
Unit Price: $137.24
sku:WAP-1496-N01SJ4-180
Real Time Availability
Stock: 10000
Quantity: Units

Type: WIFI Antenna Center Frequency: 5.8GHz Connector Series: N Connector Gender: Jack Straight Impedance: 50 Nominal Gain: 18dbi V.S.W.R: ≤1.5 Antenna Size: 260*260*90mm

Technical Specifications
Frequency Range:5.8 GHz
Input Impedance:50 Ohm
V.S.W.R.:<1.5
Gain:18 dBi
Polarization:Vertical, Linear
Max. Input Power:100 W
Connector location:Back
Connector:Standard N Female Connector

Mechanical Specifications
Dimension:260x260x90mm
Weight:Approx. 1.8kg
Radiating   Material:CuAg
Reflector Material:Electrolysis Board
Radom material:ABS
Mounting bracket:120mm x 80mm x 75mm
Horizontal Beamwidth:17 degrees
Vertical Beamwidth:18 degrees
