4G LTE SMA Male Cellular antenna 8DB Gain 3M rg174 Cable Compatible with 4G Router Trail Camera Security Camera
4G LTE Fixed Screw Mount Omni-directional SMA Male Antenna for 4G LTE Router Vehicle Truck RV Motorhome Marine Boat Mobile Cell Phone Booster System
Unit Price: $6.99
sku:4A3-0464-S01SP-080-300
quantity 1 - 9 10 - 99 100 - 500 501+
Price Each $6.99 $6.29 $5.66 ASK
saving% 0% 10% 19% -
Real Time Availability
Stock: 482
Quantity: Units

Antenna Type: Hole/Fixed/Wall/Ceiling Mount Network: 4G/LTE Antenna Frequency: 698-960 MHz, 1710-2170 MHz, 2300-2700 MHz Connector Series: SMA Connector Polarity: Standard Connector Gender: Plug Gain: 8dB Radiation: Omnidirectional V.S.W.R: <2.0 Cable Type: RG174 Cable Length: 3M Weight: 65

Compatible Carrier Network: Verizon, AT&T, T-Mobile, Sprint and etc; Frequency Range: 698-960 MHz, 1710-2170 MHz, 2300-2700 MHz; Gain: 8dBi; Direction: Omni-directional; Waterproof: Rainning Proof;



Feature: Perforated installation and 3M adhesive fixation; Antenna Mounting Screws Diameter: M12 11.76mm-11.95mm; Cable Length: 3m/10 feet; Connector: SMA Male Connector;

External omni-directional antenna (passive); Enhances cellular signal (effective in low coverage area); 10 feet cable length, SMA male connector; Bracket for easy installation; Do not require any external power;

Compatible with Spypoint Covert Spartan Tactacam 4G LTE Cellular Trail Camera, Game Camera, Wildlife Hunting Camera, Outdoor Security Camera, Celluar Surveillance Camera;

Package List: 1 x Antenna,


Specification



Frequency Range: 698-960 MHz, 1710-2170 MHz, 2300-2700 MHz

Gain: 8dBi

VSWR: ≤2.0

Impedance: 50Ω

Polarization: Linear Vertical

Feature: perforated mounting

Direction: Omni-directional;

Antenna Mounting Screws Diameter: M12 11.76mm-11.95mm

Cable Type: RG174

Cable Length: 3M

Connector: SMA-Male

RoHS/REACH compliant

Operating Temperature: -40°C to +85°C

Storage Temperature: -40°C to +90°C

Humidity: 0% to 95% (non-condensing)
