2.4GHz 16dBi WiFi Directional Panel Antenna with RP-SMA for IEEE
2.4GHz 16dBi WiFi Directional Panel Antenna with RP-SMA for IEEE
Unit Price: $50.00
sku:WAP-1554-S02SP-160-22
quantity 1 - 9 10 - 99 100 - 499 500 - 999 1000+
Price Each $50.00 $45.50 $40.50 $37.00 ASK
saving% 0% 9% 19% 26% -
Real Time Availability
Stock: 10000
Quantity: Units

Type: WIFI Antenna Center Frequency: 2.4GHz Connector Series: SMA Connector Polarity: Reverse Polarity Connector Gender: Plug Straight Impedance: 50 Nominal Gain: 16dbi V.S.W.R: ≤1.5 Antenna Size: 280mm*155mm*25mm

Description:
Frequency Range-MHZ: 2400-2483MHZ
Bandwidth-MHZ:83MHZ
Gain-dBi:16
Horizontal Beamwidt-°:30
Vertical Beamwidth-°:24
F/Bration-db>=30
V.S.W.R<=1.5
Input Impedance-Ω:50
Polarization Type:Vertical or Horizontal
Max.Power-W:100
Connector:RP-SMA Male
Antennas Dimension-mm:280mmX155mmX25mm
Weight:367g
Cable:RG58 cable
Length of the cable:220mm
